The NG SIRIO range of nitrogen generators are designed with safety and convenience in mind.  With a variety of models to suit your requirements, providing up to 8L/min of laboratory high grade nitrogen gas, users can forget about inconvenient delivery schedules and storage of high pressure gas cylinders.

These nitrogen generators remove oxygen from air to less than 5 ppm and HC pollutants to less than 0.1ppm (if the optional scrubber is installed).  The range are available with a smart low-noise piston compressor, and all are 100% oil-free.

The Ultra Pure Nitrogen is mainly used to feed ICP, ELSD, GC, FTIR and is ideal as nitrogen gas supply for Gas Chromatography, Liquid Chromatography, Mass Spectrometry, Total Organic Carbon, Inductively Coupled Plasma Spectometry and Fourier Transform – Infrared Spectometry to name just a few applications.

Common features for the NG SIRIO NG2 generators include:

  • Easy use and installation
  • Purities up to 99.9999 %
  • Pressure up to 5.5 bar
  • Flow rate up to 8 L/min
  • Long life and 100% oil free built-in compressor
  • Reduced foot print
  • Stackable with HG and ZA

Contact us today to discuss how this could benefit your chemistry.

A range of models are available to suit your requirements:

Models: NG SIRIO 1500 3000 5000 5000 HP 8000
N2 outlet
Flow rate (Max) 1500 cc/min 3000 cc/min 5000 cc/min 5000 cc/min 16 l/min 8000 cc/min
Outlet pressure (Max) 5.5 bar
(79.7 psi)
5.5 bar
(79.7 psi)
5.5 bar
(79.7 psi)
8 bar
(116 psi)
6 bar (87 psi) 5.5 bar
(79.7 psi)
Nitrogen purity*1 > 99.9999% > 99.9999% > 99.99% 99.9999% >98% >99.7%
Outlet Dew-point *2 <-60°C (-76°F)
Outlet particulate 0.01 micron
Communication
RS485 Standard
RS232 Standard
General data
Supply rating 100-115 Vac (±10%) 50/60 Hz
or
230 Vac (±10%) 50/60 Hz
Connection type IEC320-C14
Nominal power (max) 1000 W
Fuse rating (5x20mm) 10A (250VAC – T)
Net weight 90 kg
Dimensions (W x D x H) 43 x 75 x 69 cm
Pneumatic connections
Outlet port 1/4” female BSPP
Operating/storage conditions
Working Temperature 5-35°C (41-95°F)
Storage Temperature 1-50°C (34-122°F)
Humidity (max, non condensing) 70% [5-35°C (41-95°F)]
Noise < 52 dB(A)
IP rating IP20
Pollution degree rating 2 (with no aromatic compounds)
Altitude < 2000m

*1 The purity refers to the residual oxygen
*2 Atmospheric Dew Point (ADP)
