Buchi R-300 Rotary Evaporator

  • Summary
  • Specification
  • Downloads

The Buchi R-300 meets the highest expectations in convenience and versatility. Its modular design allows extension of the Rotavapor® R-300 to a fully integrated system where a central interface regulates each component.

The R-300 has a huge range of options for users to configure their perfect system.  It’s available with either an electronic or manual lift, and can optionally include the Heating Bath B-301 or B-305 and, a glass assembly of your choice and the Interface I-300 or I-300 Pro just to name a few options.  Prefer the water condenser option?  Pair with a recirculating chiller!

Ideally paired with the Vacuubrand MD 1C Vario vacuum pump.

  • Dimensions (W x D x H) with glass apparatus V 607 x 429 x 947 mm
  • Dimension (W x D x H) Shipping box 700 x 590 x 605 mm
  • Weight 13.5 kg (electric lift)
  • Weight 13.0 kg (manual lift)
  • Power supply 100 – 240 VAC ± 10%
  • Power consumption 100 W
  • Frequency 50/60 Hz
  • Ingress protection rating IP21
  • Immersion angle 10 – 50°
  • Vertical adjustment range 220 mm
  • Limit position detection adjustment range 170 mm (electric lift)
  • Limit position detection adjustment range 100 mm (manual lift)
  • Rotation speed range 10 – 280 rpm
  • Max. flask capacity 3 kg
  • Approval CE/CSA
Share with:

Description

The Buchi R-300 meets the highest expectations in convenience and versatility. Its modular design allows extension of the Rotavapor® R-300 to a fully integrated system where a central interface regulates each component.

The R-300 has a huge range of options for users to configure their perfect system.  It’s available with either an electronic or manual lift, and can optionally include the Heating Bath B-301 or B-305 and, a glass assembly of your choice and the Interface I-300 or I-300 Pro just to name a few options.  Prefer the water condenser option?  Pair with a recirculating chiller!

Ideally paired with the Vacuubrand MD 1C Vario vacuum pump.
