Medium Scale Liquid Nitrogen Generators

StirLITE medium scale liquid nitrogen generator from Asynt
  • Summary
  • Specification
  • Downloads
  • Videos

Our medium scale liquid nitrogen generators, the StirLITE system, will provide up to 3.5 L/Hr of high quality LN2 for your laboratory.

The StirLITE is a plug-and-produce solution that has a compact footprint with LN2 dispensed through a flexible hose by simply opening a valve.

We’ll take away your troublesome issues such as LN tanker deliveries (there’ll be no more evaporation or contamination problems either), we can take away all the expensive hire contracts with hidden taxes, and we can remove the issue of storing large deliveries.  By generating your own supply of liquid nitrogen on site you’re also reducing your environmental impact and, in the long term, saving money.

Key features of this range of medium scale liquid nitrogen generators include:

  • Easy Installation
  • Fully automatic operation by PLC
  • Easy liquid nitrogen dispense
  • Efficient production
  • Low noise level
  • Built for stringent climatic conditions
  • Connectable to all power supplies
  • Worldwide service & maintenance

With the integrated chiller, no water is required for cooling and operators only need to replace filters and perform routine checks between maintenance intervals of 6000 operating hours.

These laboratory LN2 generators are built to withstand a demanding environment and come with a strong worldwide support network to ensure you can safely rely on them.  We can also offer installation and servicing/maintenance contracts.

No matter how great or small your requirements for liquid nitrogen are, we can offer a generator to suit.  Please contact us now to discuss how much simpler these systems could make life in your laboratory.

The StirLITE medium scale liquid nitrogen generator:

  • Production capacity: at least 2.9 Litre of liquid nitrogen per hour
  • Storage capacity: 200 Litre
  • Purity: 99% nitrogen + inerts
  • Maintenance: every 6,000 operating hours
  • Power consumption: 9 kW (integrated chiller)
  • Power supply (3 phase): 200 to 480 V, 50/60 Hz (as per client’s local requirements)
  • Start-up time: within 10 minutes
  • Start/stop procedure: fully automatic, single switch operation
  • Advised plant room (l x w x h): 3,50 x 3,50 x 3.00 m
  • Weight: 1.350 kg
  • Ambient temperature: up to 45 °C, 113 °F
  • Relative humidity: up to 95%
  • Storage vessel pressure: 1 bar(g)
  • Site installation:
  • Noise level: ≤72 dBA

Please note that other models are available with both higher and lower production rates so please contact us to discuss your requirements.
