The 2mag atexMIXdrive 1

The 2mag atexMIXdrive 1
  • Summary
  • Specification
  • Associated Products

1 stirring position, 100% maintenance-free and wear-free by inductive 2mag-Magnetic-Drive concept for powerful mixing of solutions, jerk-free stirring even at low speeds.

Fully encapsulated and hermetically sealed stainless steel housing, IP68, water-, dust- and germproof, extremely robust construction and performance, easy to clean and maximum resistance, submersible in water- resp. oil baths, suitable for the use in CO2-incubators and ovens, temperate range up to +40 °C, certified according to ATEX II 2G Ex mb IIC T4.

Stirring volume 1 – 10.000 ml
Stirring power (max.) 20 W
Material housing Stainless steel
Operation temperature -10 °C up to +40 °C in air, up to+40 °C in water
Operating voltage 48 VDC
Dimensions (WxDxH) 180 x 180 x 38 mm
Protection category IP 68
Weight 3.5 kg
Ex-mark ATEX II 2G Ex mb IIC T4
Certificate of conformity EPS 14 ATEX 1 701 X
Share with:

Description

1 stirring position, 100% maintenance-free and wear-free by inductive 2mag-Magnetic-Drive concept for powerful mixing of solutions, jerk-free stirring even at low speeds.

Fully encapsulated and hermetically sealed stainless steel housing, IP68, water-, dust- and germproof, extremely robust construction and performance, easy to clean and maximum resistance, submersible in water- resp. oil baths, suitable for the use in CO2-incubators and ovens, temperate range up to +40 °C, certified according to ATEX II 2G Ex mb IIC T4.
